1050s automatic stripping and platen die cutting machine is manufactured by the shanghai eterna machinery co., ltd,which can be divided into five parts:feeding system for paper part,feeding positioning,die cutting,stripping,stacker.its maximum paper size is 1050 x 750 mm,minium paper size is 400 x 360 mm,maximum cutting range is 1040 x 720 mm,maximum template size is 1080 x 745 mm,die cutting steel plate size is 1080 x 736 mm,applicable paper scope is 80~600g/m2 cardboard,corrugated cardboard thickness is less than or equal to 4mm, min mouthpiece width is 8mm,maximum mechanical speed is 7500/h,maximum pressure shearing force is 300 ton.1050s automatic stripping and platen die cutting machine 's feeding system is very stable,which help to thin paper,it has high precision of product processing and effective removing waste,which help to stable recovery of finished product.the import of this machine improves the process of colour box,and help the company's business development.
