pm series inkjet code delivery platform is a professional equipment for sheet-fed printing of barcode, two-dimensional code and other variable information. any type of inkjet code system can be installed on the platform for variable information printing.
technical parameters:
maximum paper size 1040*1020
minimum paper size 300*420
paper quality 100-450g/㎡
* maximum speed: 80m/min
power 30 kw
ir drying 20 kw
product features:
1, automatic feeding cover
adopt offset printing press to feed paper feida.high speed and stability.optional: prestack paper device
2, powder removal compaction part sleeve (optional)
the paper dust can be effectively removed by two ways: double brush roller and heating roller compaction.reduce the nozzle blockage, improve the quality of printing.
3, side provisions of the position set
lengthened ball inclined pull specified position, accurate positioning of paper, positioning accuracy in ±0.2mm.
mechanical two-tensioned controller.
4, vacuum adsorption platform part cover
vacuum platform adsorption area up to 2450mm, to ensure the maximum paper in the vacuum platform to complete printing.
special wide vacuum belt, paper flat, stable.
adopt low noise vacuum fan, suitable for paper of different weight.
5, the drying cadre set (according to the ink-jet system to choose the drying method)
infrared baking cadre sleeve:
drying power 20kv, pid control, temperature adjustable.
adopt teflon high temperature resistant mesh belt.
adopt circulation hot air, make drying more fully.
the drying box can automatically lift the cylinder.
6, dry cadre sets
increase the cooling air device, ink fast drying, and reduce the surface temperature of paper.
the air drying box can be lifted by the cylinder to avoid paper blocking.
7, waste removal device (optional.need to cooperate with online detection system)
it can automatically remove the defects such as heavy code, missing code and failing to read the barcode, so as to ensure the barcode quality of the delivered printing products.
8, automatic paper collection cover
automatic stacking paper collection.
adopt pneumatic colliding device, paper stack more neat.
