ytp-260r7c 1 全轮转凸版印刷机


产品介绍:
▲世界首创多功能组台机,镭射转印涂胶上膜功能齐全,前中后冷烫一机达成
▲the  worid's     first  innovatio  of multifunction   combination machine   with the polymar-coatad gelatinize and anterior middle posteror cold foil.
specification规格 :
印刷座printing station(sets)7
上金油flexo varnishing station(part)(set)1
传动齿轮gearing(cp)1/8*
最大纸宽max.paper width(mm)260
最大印刷宽max.printing width(mm)250
送纸径(最大)送纸径(最大)(mm)800
复卷径(最大)rewind roll dia.max(mm)800
印刷长度最长max.(mm)460.375
print length最短min.(mm)190.5
最大印刷速度max.printing speed(m/min)100
机械重量浮重net weight(kgs)8100
machine weight毛重 gross weight(kgs)9100

主机马达main motor380v(kw)7.5
耗电与马达匀墨马达(7个)stirring motor(7pcs)

power&motoruv乾燥8套(uv dryer8sets) 5kw/pc 7lamps(w)1400

                                           7kw/pc llamps(kw)42
机械尺寸machine size l*w*h(m)6.2×1.6×2.2
标准配备:standard  accessories
印刷座七座printing  station7sets
版胴(尺寸任选)五套printing  cylinder(size  optional)5sets
uv六座uv dryer7sets
修纸边七套paper slitting system1set
工具一套tools1set
贴版台一套biock setting tabie1set
封边器一套automatic web guiding system1set
接纸台一套splicing platform1set
上金油座(含uv系统)一套flexo  varnishing  syste with uv dryer1set
可乐娜表面处理器
corona treater (foil can be treated)
胶裹和背面印刷设备
back side printing device
圆垫模切座
rotary die cutting device
静电消除器
electrostatic eliminato.



选购配备:the selects and purchases equipments:
冷烫系统cole foil system
凹版印刷系统intaglio plate printing system
圆纲版印刷系统rotary screen printing system
切单张系统cuts the single sheet system
静态观测系统static state observation sysiem
冷却系统cooling system
适用材料suitable materlals
贴纸、积层材、bopp膜、收缩膜、
石化附属环保材料和特殊材料等
adhesive paper,laminatem materials bopp film,shrinkable film
styrofam and othe special materials
适用刀模:磁性圆刀模、雕刻圆胴刀模suitable die-cuttling:magnetic cylinder,flexible plate,rotarydie
cut,rotaoy hard dies.
印版版材:树脂版standard plate making reference:photopolymer plate
版材硬度45°~55°度plate hardness:45°~55°
版材厚度0.95mmplate thickness:0.95mm
洗刷深赓0.69mm(参考)depth:0.69mm(reference)
